Music in Motion: Dancing Quadrocopters
This project features agile, multi-vehicle flight performances that are designed and executed to music. We develop motion planning, control and learning algorithms that result in collision-free, perfectly timed flight motions. Enjoy!
The original project page at ETH Zurich with more details is found here. More recently, we have revisited this project using large language models to generate choreographies for quadrotor swarms.
Related Publications
Swarm-GPT
This paper presents Swarm-GPT, a system that integrates large language models (LLMs) with safe swarm motion planning – offering an automated and novel approach to deployable drone swarm choreography. Swarm-GPT enables users to automatically generate synchronized drone performances through natural language instructions. With an emphasis on safety and creativity, Swarm-GPT addresses a critical gap in the field of drone choreography by integrating the creative power of generative models with the effectiveness and safety of model-based planning algorithms. This goal is achieved by prompting the LLM to generate a unique set of waypoints based on extracted audio data. A trajectory planner processes these waypoints to guarantee collision-free and feasible motion. Results can be viewed in simulation prior to execution and modified through dynamic re-prompting. Sim-to-real transfer experiments demonstrate Swarm-GPT’s ability to accurately replicate simulated drone trajectories, with a mean sim-to-real root mean square error (RMSE) of 28.7 mm. To date, Swarm-GPT has been successfully showcased at three live events, exemplifying safe real-world deployment of pre-trained models.
@MISC{jiao-neurips23,
author = {Aoran Jiao and Tanmay P. Patel and Sanjmi Khurana and Anna-Mariya Korol and Lukas Brunke and Vivek K. Adajania and Utku Culha and Siqi Zhou and Angela P. Schoellig},
title = {{Swarm-GPT}: Combining Large Language Models with Safe Motion Planning for Robot Choreography Design},
year = {2023},
howpublished = {Extended Abstract in the 6th Robot Learning Workshop at the Conference on Neural Information Processing Systems (NeurIPS)},
urllink = {https://arxiv.org/abs/2312.01059},
abstract = {This paper presents Swarm-GPT, a system that integrates large language models (LLMs) with safe swarm motion planning - offering an automated and novel approach to deployable drone swarm choreography. Swarm-GPT enables users to automatically generate synchronized drone performances through natural language instructions. With an emphasis on safety and creativity, Swarm-GPT addresses a critical gap in the field of drone choreography by integrating the creative power of generative models with the effectiveness and safety of model-based planning algorithms. This goal is achieved by prompting the LLM to generate a unique set of waypoints based on extracted audio data. A trajectory planner processes these waypoints to guarantee collision-free and feasible motion. Results can be viewed in simulation prior to execution and modified through dynamic re-prompting. Sim-to-real transfer experiments demonstrate Swarm-GPT's ability to accurately replicate simulated drone trajectories, with a mean sim-to-real root mean square error (RMSE) of 28.7 mm. To date, Swarm-GPT has been successfully showcased at three live events, exemplifying safe real-world deployment of pre-trained models.},
}
Summary and Overview Papers
This chapter presents a set of algorithms that enable quadrotor vehicles to “fly with the music”; that is, to perform rhythmic motions that are aligned with the beat of a given music piece.
@INCOLLECTION{schoellig-springer14,
author = {Angela P. Schoellig and Hallie Siegel and Federico Augugliaro and Raffaello D'Andrea},
title = {So you think you can dance? {Rhythmic} flight performances with quadrocopters},
booktitle = {{Controls and Art}},
editor = {Amy LaViers and Magnus Egerstedt},
publisher = {Springer International Publishing},
pages = {73-105},
year = {2014},
doi = {10.1007/978-3-319-03904-6_4},
urldata={../../wp-content/papercite-data/data/schoellig-springer14-files.zip},
urlslides={../../wp-content/papercite-data/slides/schoellig-springer14-slides.pdf},
urllink = {http://www.tiny.cc/MusicInMotionSite},
urlvideo={https://www.youtube.com/playlist?list=PLD6AAACCBFFE64AC5},
abstract = {This chapter presents a set of algorithms that enable quadrotor vehicles to "fly with the music"; that is, to perform rhythmic motions that are aligned with the beat of a given music piece.}
}
Dance of the flying machines: methods for designing and executing an aerial dance choreographyF. Augugliaro, A. P. Schoellig, and R. D’AndreaIEEE Robotics Automation Magazine, vol. 20, iss. 4, pp. 96-104, 2013.
Imagine a troupe of dancers flying together across a big open stage, their movement choreographed to the rhythm of the music. Their performance is both coordinated and skilled; the dancers are well rehearsed, and the choreography well suited to their abilities. They are no ordinary dancers, however, and this is not an ordinary stage. The performers are quadrocopters, and the stage is the ETH Zurich Flying Machine Arena, a state-of-the-art mobile testbed for aerial motion control research.
@ARTICLE{augugliaro-ram13,
author = {Federico Augugliaro and Angela P. Schoellig and Raffaello D'Andrea},
title = {Dance of the Flying Machines: Methods for Designing and Executing an Aerial Dance Choreography},
journal = {{IEEE Robotics Automation Magazine}},
volume = {20},
number = {4},
pages = {96-104},
year = {2013},
doi = {10.1109/MRA.2013.2275693},
urlvideo={http://youtu.be/NRL_1ozDQCA?t=21s},
urlslides={../../wp-content/papercite-data/slides/augugliaro-ram13-slides.pdf},
abstract = {Imagine a troupe of dancers flying together across a big open stage, their movement choreographed to the rhythm of the music. Their performance is both coordinated and skilled; the dancers are well rehearsed, and the choreography well suited to their abilities. They are no ordinary dancers, however, and this is not an ordinary stage. The performers are quadrocopters, and the stage is the ETH Zurich Flying Machine Arena, a state-of-the-art mobile testbed for aerial motion control research.}
}
Periodic Motion Planning, Control and Learning
This paper presents an algorithm that generates collision-free trajectories in three dimensions for multiple vehicles within seconds. The problem is cast as a non-convex optimization problem, which is iteratively solved using sequential convex programming that approximates non-convex constraints by using convex ones. The method generates trajectories that account for simple dynamics constraints and is thus independent of the vehicle’s type. An extensive a posteriori vehicle-specific feasibility check is included in the algorithm. The algorithm is applied to a quadrocopter fleet. Experimental results are shown.
@INPROCEEDINGS{augugliaro-iros12,
author = {Federico Augugliaro and Angela P. Schoellig and Raffaello D'Andrea},
title = {Generation of collision-free trajectories for a quadrocopter fleet: A sequential convex programming approach},
booktitle = {{Proc. of the IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS)}},
pages = {1917-1922},
year = {2012},
doi = {10.1109/IROS.2012.6385823},
urlvideo = {https://youtu.be/wwK7WvvUvlI?list=PLD6AAACCBFFE64AC5},
abstract = {This paper presents an algorithm that generates collision-free trajectories in three dimensions for multiple vehicles within seconds. The problem is cast as a non-convex optimization problem, which is iteratively solved using sequential convex programming that approximates non-convex constraints by using convex ones. The method generates trajectories that account for simple dynamics constraints and is thus independent of the vehicle's type. An extensive a posteriori vehicle-specific feasibility check is included in the algorithm. The algorithm is applied to a quadrocopter fleet. Experimental results are shown.}
}
Feed-forward parameter identification for precise periodic quadrocopter motionsA. P. Schoellig, C. Wiltsche, and R. D’Andreain Proc. of the American Control Conference (ACC), 2012, pp. 4313-4318.
This paper presents an approach for precisely tracking periodic trajectories with a quadrocopter. In order to improve temporal and spatial tracking performance, we propose a feed-forward strategy that adapts the motion parameters sent to the vehicle controller. The motion parameters are either adjusted on the fly or, in order to avoid initial transients, identified prior to the flight performance. We outline an identification scheme that tunes parameters for a large class of periodic motions, and requires only a small number of identification experiments prior to flight. This reduced identification is based on analysis and experiments showing that the quadrocopter’s closed-loop dynamics can be approximated by three directionally decoupled linear systems. We show the effectiveness of this approach by performing a sequence of periodic motions on real quadrocopters using the tuned parameters obtained by the reduced identification.
@INPROCEEDINGS{schoellig-acc12,
author = {Angela P. Schoellig and Clemens Wiltsche and Raffaello D'Andrea},
title = {Feed-forward parameter identification for precise periodic quadrocopter motions},
booktitle = {{Proc. of the American Control Conference (ACC)}},
pages = {4313-4318},
year = {2012},
doi = {10.1109/ACC.2012.6315248},
urlvideo = {http://tiny.cc/MusicInMotion},
urlslides = {../../wp-content/papercite-data/slides/schoellig-acc12-slides.pdf},
abstract = {This paper presents an approach for precisely tracking periodic trajectories with a quadrocopter. In order to improve temporal and spatial tracking performance, we propose a feed-forward strategy that adapts the motion parameters sent to the vehicle controller. The motion parameters are either adjusted on the fly or, in order to avoid initial transients, identified prior to the flight performance. We outline an identification scheme that tunes parameters for a large class of periodic motions, and requires only a small number of identification experiments prior to flight. This reduced identification is based on analysis and experiments showing that the quadrocopter's closed-loop dynamics can be approximated by three directionally decoupled linear systems. We show the effectiveness of this approach by performing a sequence of periodic motions on real quadrocopters using the tuned parameters obtained by the reduced identification.}
}
Feasibility of motion primitives for choreographed quadrocopter flightA. P. Schoellig, M. Hehn, S. Lupashin, and R. D’Andreain Proc. of the American Control Conference (ACC), 2011, pp. 3843-3849.
This paper describes a method for checking the feasibility of quadrocopter motions. The approach, meant as a validation tool for preprogrammed quadrocopter performances, is based on first principles models and ensures that a desired trajectory respects both vehicle dynamics and motor thrust limits. We apply this method towards the eventual goal of using parameterized motion primitives for expressive quadrocopter choreographies. First, we show how a large class of motion primitives can be formulated as truncated Fourier series. We then show how the feasibility check can be applied to such motions by deriving explicit parameter constraints for two particular parameterized primitives. The predicted feasibility constraints are compared against experimental results from quadrocopters in the ETH Flying Machine Arena.
@INPROCEEDINGS{schoellig-acc11,
author = {Angela P. Schoellig and Markus Hehn and Sergei Lupashin and Raffaello D'Andrea},
title = {Feasibility of motion primitives for choreographed quadrocopter flight},
booktitle = {{Proc. of the American Control Conference (ACC)}},
pages = {3843-3849},
year = {2011},
doi = {10.1109/ACC.2011.5991482},
urlvideo = {https://www.youtube.com/playlist?list=PLD6AAACCBFFE64AC5},
urlslides = {../../wp-content/papercite-data/slides/schoellig-acc11-slides.pdf},
urldata = {../../wp-content/papercite-data/data/schoellig-acc11-files.zip},
abstract = {This paper describes a method for checking the feasibility of quadrocopter motions. The approach, meant as a validation tool for preprogrammed quadrocopter performances, is based on first principles models and ensures that a desired trajectory respects both vehicle dynamics and motor thrust limits. We apply this method towards the eventual goal of using parameterized motion primitives for expressive quadrocopter choreographies. First, we show how a large class of motion primitives can be formulated as truncated Fourier series. We then show how the feasibility check can be applied to such motions by deriving explicit parameter constraints for two particular parameterized primitives. The predicted feasibility constraints are compared against experimental results from quadrocopters in the ETH Flying Machine Arena.}
}
A platform for dance performances with multiple quadrocoptersA. P. Schoellig, F. Augugliaro, and R. D’Andreain Proc. of the Workshop on Robots and Musical Expressions at the IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS), 2010, pp. 1-8.
This paper presents a platform for rhythmic flight with multiple quadrocopters. We envision an expressive multimedia dance performance that is automatically composed and controlled, given a random piece of music. Results in this paper prove the feasibility of audio-motion synchronization when precisely timing the side-to-side motion of a quadrocopter to the beat of the music. An illustration of the indoor flight space and the vehicles shows the characteristics and capabilities of the experimental setup. Prospective features of the platform are outlined and key challenges are emphasized. The paper concludes with a proof-of-concept demonstration showing three vehicles synchronizing their side-to-side motion to the music beat. Moreover, a dance performance to a remix of the sound track ‘Pirates of the Caribbean’ gives a first impression of the novel musical experience. Future steps include an appropriate multiscale music analysis and the development of algorithms for the automated generation of choreography based on a database of motion primitives.
@INPROCEEDINGS{schoellig-iros10,
author = {Angela P. Schoellig and Federico Augugliaro and Raffaello D'Andrea},
title = {A platform for dance performances with multiple quadrocopters},
booktitle = {{Proc. of the Workshop on Robots and Musical Expressions at the IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS)}},
pages = {1-8},
year = {2010},
urlvideo = {https://youtu.be/aaaGJKnJdrg?list=PLD6AAACCBFFE64AC5},
urlvideo2 = {https://www.youtube.com/playlist?list=PLD6AAACCBFFE64AC5},
urlslides = {../../wp-content/papercite-data/slides/schoellig-iros10-slides.pdf},
abstract = {This paper presents a platform for rhythmic flight with multiple quadrocopters. We envision an expressive multimedia dance performance that is automatically composed and controlled, given a random piece of music. Results in this paper prove the feasibility of audio-motion synchronization when precisely timing the side-to-side motion of a quadrocopter to the beat of the music. An illustration of the indoor flight space and the vehicles shows the characteristics and capabilities of the experimental setup. Prospective features of the platform are outlined and key challenges are emphasized. The paper concludes with a proof-of-concept demonstration showing three vehicles synchronizing their side-to-side motion to the music beat. Moreover, a dance performance to a remix of the sound track 'Pirates of the Caribbean' gives a first impression of the novel musical experience. Future steps include an appropriate multiscale music analysis and the development of algorithms for the automated generation of choreography based on a database of motion primitives.}
}
Synchronizing the motion of a quadrocopter to musicA. P. Schoellig, F. Augugliaro, and R. D’Andreain Proc. of the IEEE International Conference on Robotics and Automation (ICRA), 2010, pp. 3355-3360.
This paper presents a quadrocopter flying in rhythm to music. The quadrocopter performs a periodic side-to-side motion in time to a musical beat. Underlying controllers are designed that stabilize the vehicle and produce a swinging motion. Synchronization is then achieved by using concepts from phase-locked loops. A phase comparator combined with a correction algorithm eliminate the phase error between the music reference and the actual quadrocopter motion. Experimental results show fast and effective synchronization that is robust to sudden changes in the reference amplitude and frequency. Changes in frequency and amplitude are tracked precisely when adding an additional feedforward component, based on an experimentally determined look-up table.
@INPROCEEDINGS{schoellig-icra10,
author = {Angela P. Schoellig and Federico Augugliaro and Raffaello D'Andrea},
title = {Synchronizing the motion of a quadrocopter to music},
booktitle = {{Proc. of the IEEE International Conference on Robotics and Automation (ICRA)}},
pages = {3355-3360},
year = {2010},
doi = {10.1109/ROBOT.2010.5509755},
urlslides = {../../wp-content/papercite-data/slides/schoellig-icra10-slides.pdf},
urlvideo = {https://youtu.be/Kx4DtXv_bPo?list=PLD6AAACCBFFE64AC5},
abstract = {This paper presents a quadrocopter flying in rhythm to music. The quadrocopter performs a periodic side-to-side motion in time to a musical beat. Underlying controllers are designed that stabilize the vehicle and produce a swinging motion. Synchronization is then achieved by using concepts from phase-locked loops. A phase comparator combined with a correction algorithm eliminate the phase error between the music reference and the actual quadrocopter motion. Experimental results show fast and effective synchronization that is robust to sudden changes in the reference amplitude and frequency. Changes in frequency and amplitude are tracked precisely when adding an additional feedforward component, based on an experimentally determined look-up table.}
}
Experimental Platform
The Flying Machine Arena is a platform for experiments and demonstrations with fleets of small flying vehicles. It utilizes a distributed, modular architecture linked by robust communication layers. An estimation and control framework along with built-in system protection components enable prototyping of new control systems concepts and implementation of novel demonstrations. More recently, a mobile version has been featured at several eminent public events. We describe the architecture of the Arena from the viewpoint of system robustness and its capability as a dual-purpose research and demonstration platform.
@ARTICLE{lupashin-mech14,
author = {Sergei Lupashin and Markus Hehn and Mark W. Mueller and Angela P. Schoellig and Raffaello D'Andrea},
title = {A platform for aerial robotics research and demonstration: {The Flying Machine Arena}},
journal = {{Mechatronics}},
volume = {24},
number = {1},
pages = {41-54},
year = {2014},
doi = {10.1016/j.mechatronics.2013.11.006},
urllink = {http://flyingmachinearena.org/},
urlvideo={https://youtu.be/pcgvWhu8Arc?list=PLuLKX4lDsLIaVjdGsZxNBKLcogBnVVFQr},
abstract = {The Flying Machine Arena is a platform for experiments and demonstrations with fleets of small flying vehicles. It utilizes a distributed, modular architecture linked by robust communication layers. An estimation and control framework along with built-in system protection components enable prototyping of new control systems concepts and implementation of novel demonstrations. More recently, a mobile version has been featured at several eminent public events. We describe the architecture of the Arena from the viewpoint of system robustness and its capability as a dual-purpose research and demonstration platform.}
}
The Flying Drum Machine
This paper proposes the use of a quadrotor aerial vehicle as a musical instrument. Using the idea of interactions based on physical contact, a system is developed that enables humans to engage in artistic expression with a flying robot and produce music. A robotic user interface that uses physical interactions was created for a quadcopter. The interactive quadcopter was then programmed to drive playback of drum sounds in real-time in response to physical interaction. An intuitive mapping was developed between machine movement and art/creative composition. Challenges arose in meeting realtime latency requirements mainly due to delays in input detection. They were overcome through the development of a quick input detection method, which relies on accurate yet fast digital filtering. Successful experiments were conducted with a professional musician who used the interface to compose complex rhythm patterns. A video accompanying this paper demonstrates his performance.
@TECHREPORT{wang-tr15,
author = {Xingbo Wang and Natasha Dalal and Tristan Laidlow and Angela P. Schoellig},
title = {A Flying Drum Machine},
year = {2015},
urlvideo={https://youtu.be/d5zG-BWB7lE?list=PLD6AAACCBFFE64AC5},
abstract = {This paper proposes the use of a quadrotor aerial vehicle as a musical instrument. Using the idea of interactions based on physical contact, a system is developed that enables humans to engage in artistic expression with a flying robot and produce music. A robotic user interface that uses physical interactions was created for a quadcopter. The interactive quadcopter was then programmed to drive playback of drum sounds in real-time in response to physical interaction. An intuitive mapping was developed between machine movement and art/creative composition. Challenges arose in meeting realtime latency requirements mainly due to delays in input detection. They were overcome through the development of a quick input detection method, which relies on accurate yet fast digital filtering. Successful experiments were conducted with a professional musician who used the interface to compose complex rhythm patterns. A video accompanying this paper demonstrates his performance.}
}
